Porous Sintered Metal Filter Tube SS 316L For Catalyst Recovery Chemical
| Place of Origin | China |
|---|---|
| Brand Name | CSTY |
| Certification | ISO 9001;2015 |
| Model Number | SS 316L |
| Minimum Order Quantity | 5-10pcs |
| Price | USD56/pc |
| Packaging Details | film and wooden case,carton Packaging can be according to customer requirements. |
| Delivery Time | 10-15days |
| Payment Terms | L/C, T/T, Western Union, MoneyGram,paypal |
| Supply Ability | 200pcs/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Abrasion Resistance | High | Temperature Resistance | ≤400℃ |
|---|---|---|---|
| Sample Service | Provide Sample For Testing | Max Pressure | 2.0Mpa |
| Material | SS 316L, Titanium, Inconel600, Monel400, Etxc. | Other Service | Platium, Ir, Ru Coating Titanium Plate |
| Surface Treatment | Polishing | Filtration Area | 0.3-1.0m2 |
| Advantage | High Porosity And Permeability | Type | Titanium Filter Element |
| Compressive Strength | ≥0.6MPa | Filter Rating | 0.5um-50um |
| Filter Media | Nickel Powder | Working Life | More Than 10 Years |
| Temperature | 0-200℃ |
Product Description
Introduction
Compared with traditional filtration materials such as paper, cotton, PP, PE, PES, and PTFE, metal powder sintered porous materials offer superior performance.
They feature excellent permeability, uniform pore size and pore control, stable shape, high filtration accuracy, wear resistance, and outstanding mechanical strength.
Additionally, these materials exhibit good heat conduction, heat resistance, and dissipation performance, allowing them to be washed and reused multiple times without significant loss of performance.
Specifications
| Product Name | SS 316L Sintered Tube |
|---|---|
| Material | Pure Titanium / SS316L / Bronze |
| Size | OD 20–80 mm × WT 2.5–3.0 mm × L 10–1200 mm |
| Filter Accuracy | 0.5–80 µm |
| Connection | Customized according to customer requirements |
| Applications | Sparging, Separation and Filtration, Carbonation, Liquid Filtration, etc. |
Technical Parameters
| Filter Accuracy (µm) | Porosity (%) | Permeability (m³/m²·h·kPa) | Compression Strength (MPa) | Temperature Tolerance (°C) | Max Working Pressure (MPa) |
|---|---|---|---|---|---|
| 0.5–50 | 20–50 | 3–800 | 2–3 | 250 | 0.6 |
Performance Features
Excellent mechanical strength and structural stability
Uniform pore size distribution and good air permeability
Superior chemical stability and corrosion resistance
High temperature resistance (up to 250 °C)
Acid and alkali resistance
Fireproof, anti-static, and reusable
Long service life with consistent filtration efficiency
Application Environments
Suitable for use in environments containing:
Nitric acid, sulfuric acid, acetic acid, oxalic acid, phosphoric acid, 5% hydrochloric acid, molten sodium, liquid hydrogen, liquid nitrogen, hydrogen sulfide, acetylene, water vapor, hydrogen gas, coal gas, carbon dioxide gas, and other chemically aggressive media.
Widely used in:
Catalyst recovery and chemical processing
Beverage and food production
Metallurgy and refining
Coarse and fine liquid filtration
Dust and oil mist removal from gases and vapors
Sound attenuation, flame retardancy, and gas buffering applications
