Titanium Round Bar Gr7 Alloy ASTM B348 Titanium Connecting Bar

  • Titanium Round Bar Gr7 Alloy ASTM B348 Titanium Connecting Bar
  • Titanium Round Bar Gr7 Alloy ASTM B348 Titanium Connecting Bar
  • Titanium Round Bar Gr7 Alloy ASTM B348 Titanium Connecting Bar
  • Titanium Round Bar Gr7 Alloy ASTM B348 Titanium Connecting Bar
  • Titanium Round Bar Gr7 Alloy ASTM B348 Titanium Connecting Bar
  • Titanium Round Bar Gr7 Alloy ASTM B348 Titanium Connecting Bar
Place of Origin China
Brand Name Changsheng
Certification ISO 9001
Model Number ASTM
Minimum Order Quantity 50kg
Price 15usd/kg
Packaging Details wooden case,carton Packaging can be according to customer requirements.
Delivery Time 15~20 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Materials Titanium Grade Grade 1,Grade 5, Ti-6al-4v,grade 2,grade 4,grade 23,grade 7,grade 11
Diameter 3-600mm MOQ 50kg
Surface Polished, Pickling Technical Forged
Standard ASTM B348,AMS 4904,ASTM F67,ASTM F136 Delivert Time 7-10days
Highlight

6000mm Titanium Round Bar

,

ASTM F67 Titanium Round Bar

,

ASTM F136 bright bar
Leave a Message
Product Description

Description



Titanium Gr5 Round Bar ASTM B348 is a high-strength, lightweight, and corrosion-resistant metal alloy composed primarily of titanium, aluminum, and vanadium. Known for its excellent strength-to-weight ratio, Gr5 titanium rods are widely used in aerospace, defense, medical implants, chemical processing, and marine applications.

Titanium Gr5 rods are biocompatible, making them suitable for medical implants and instruments. They are available in various sizes, lengths, and custom shapes, including flanged or stepped rods, to meet different engineering and manufacturing requirements.

Specifications

Material: Titanium Alloy

Grade: Grade 5 / Ti-6Al-4V / R56400

Standard: ASTM B348

Diameter: 3–600 mm

Length: 100–6000 mm

Surface Finish: Polished (custom finishes available)

Custom Sizes: Available on request

Physical Properties

Grade Tensile Strength (MPa) Yield Strength (MPa) Elongation (%)
Gr1 240 170 24
Gr2 345 275 20
Gr4 550 483 15
Gr5 895 828 10
Gr7 400 275 18
Gr9 620 483 15
Gr12 483 348 18
Gr23 793 759 10

Chemical Composition (Gr5 / Ti-6Al-4V)

Element Max (wt %)
Fe 0.4
O 0.2
N 0.05
C 0.08
H 0.015
Al 5.5–6.7
V 3.5–4.5
Ti Balance

Applications

Aerospace & Jet Engines: Strengthening frames and components due to high-temperature resistance and lightweight properties.

Chemical & Petrochemical Plants: Seawater desalination, LNG plants, and petroleum refineries.

Automotive & Motorcycles: Components such as mufflers and structural parts.

Medical: Artificial bones, surgical instruments, pacemakers, and implants.

Sports & Leisure: Golf clubs, tennis rackets, ski plates, bicycles.

Jewelry: Lightweight, non-allergenic, and stylish earrings, necklaces, and cufflinks.

Advantages

  1. High strength-to-weight ratio

  2. Excellent corrosion resistance

  3. Biocompatible for medical applications

  4. Non-magnetic and good electrical/thermal conductivity

  5. Easy to machine, weld, and fabricate

  6. Available in various sizes and custom shapes

Tags:

ASTM B348 Titanium Round Bar

gr23 titanium round bar

ASTM F136 round bar titanium
