Titanium Hex Bar ASTM B348 TA1 TA2 TA9 Titanium Hexagon Rod Electroplate

  • Titanium Hex Bar ASTM B348 TA1 TA2 TA9 Titanium Hexagon Rod Electroplate
  • Titanium Hex Bar ASTM B348 TA1 TA2 TA9 Titanium Hexagon Rod Electroplate
  • Titanium Hex Bar ASTM B348 TA1 TA2 TA9 Titanium Hexagon Rod Electroplate
  • Titanium Hex Bar ASTM B348 TA1 TA2 TA9 Titanium Hexagon Rod Electroplate
  • Titanium Hex Bar ASTM B348 TA1 TA2 TA9 Titanium Hexagon Rod Electroplate
  • Titanium Hex Bar ASTM B348 TA1 TA2 TA9 Titanium Hexagon Rod Electroplate
Place of Origin CHINA
Brand Name Changsheng
Certification ISO 9001
Model Number DIN
Minimum Order Quantity 50kg
Price 15usd/kg
Packaging Details film and wooden case,carton Packaging can be according to customer requirements.
Delivery Time 15~20 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 5000 Kilogram/Kilograms per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Materials Titanium Grade Grade 1,Grade 5, Ti-6al-4v,grade 2,grade 4,grade 23,grade 7,grade 11
Diameter 10-100mm Surface Polished, Pickling
MOQ 50KG Standard ASTM B348,AMS 4904,ASTM F67,ASTM F136
Technical Forged, Rolled Delivery Time 15-20days
Highlight

AMS 4904 Titanium Round Bar

,

Acid Pickling Titanium Round Bar

,

gr11 titanium hex bar
Leave a Message
Product Description

Description



Titanium Hex Bar ASTM B348 is a high-performance, bar-shaped product made from titanium and its alloys, featuring a hexagonal cross-section.
These bars are available in a wide range of sizes and grades to suit diverse industrial applications.

Titanium hexagonal rods are known for their light weight, high strength, and outstanding corrosion resistance, making them widely used in the aerospace, medical, marine, chemical, and automotive industries. Their excellent mechanical and thermal properties also make them suitable for precision machining and high-stress structural components.

Stock Information

Size (Across Flats): 10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 25mm, 30mm, 35mm, 40mm (custom sizes available)

Grade: Gr1, Gr2, Gr5, Gr7, Gr9, Gr12, Gr23

Length: 1000–6000 mm

Standard: ASTM B348, ASTM B381

Surface Finish: Polished or Pickled

Physical Properties

Grade Tensile Strength (MPa) Yield Strength (MPa) Elongation (%)
Gr1 240 170 24
Gr2 345 275 20
Gr4 550 483 15
Gr5 895 828 10
Gr7 400 275 18
Gr9 620 483 15
Gr12 483 348 18
Gr23 793 759 10

Chemical Composition (Wt%)

Grade Fe O N C H Pd Al V Ni Mo
Gr1 0.20 0.18 0.03 0.08 0.015 — — — — —
Gr2 0.30 0.25 0.03 0.08 0.015 — — — — —
Gr4 0.50 0.40 0.05 0.08 0.015 — — — — —
Gr5 0.40 0.20 0.05 0.08 0.015 — 5.5–6.7 3.5–4.5 — —
Gr7 0.30 0.25 0.03 0.08 0.015 0.12–0.25 — — — —
Gr9 0.25 0.15 0.03 0.08 0.015 — 2.5–3.5 2.0–3.0 — —
Gr12 0.30 0.25 0.03 0.08 0.015 — — — 0.6–0.9 0.2–0.4
Gr23 0.25 0.03 0.03 0.08 0.0125 — 5.5–6.5 3.5–4.5 — —
Ti Balance

Advantages

  1. Lightweight and High Strength – Excellent strength-to-weight ratio ideal for aerospace and marine applications.

  2. Corrosion Resistance – Superior performance in seawater, acids, and industrial chemical environments.

  3. Non-Magnetic and Conductive – Offers good electrical and thermal conductivity.

  4. Fatigue Resistance – Withstands repeated mechanical stress without structural failure.

  5. Machinability and Weldability – Easily fabricated into complex components.

  6. Customizable – Available in various diameters, lengths, and surface finishes upon request.

Applications

Aerospace components and structural fasteners

Medical and surgical instruments

Marine fittings and offshore structures

Automotive and racing parts

Chemical processing equipment

Industrial machinery and tooling
