Titanium Plate Production Capability

The tabulation below provides a summary overview to the production capability.

• Production standard: ASTM B265, ASME SB265, AMS 4902, AMS4901, AMS4911, ASTM F136, ASTM F67
• Titanium Grades: Gr 1, 2, 3, 4, 5(6Al-4V), 7(Ti-0.15Pd), 9(3Al-2.5V), 12, 23(6AL-4V ELI), 15V-3Al-3Sn-3Cr,etc,.
• Titanium Sheet Dimensions: Thickness: 0.4 – 300 mm, Length: 1000 – 6000 mm, Width: 400 – 2800 mm
• Titanium Sheet Surface Finishes: Polished, Mill, Pickling, Painted, Sandblasted
• Services offered: Waterjet cutting, laser cutting, welding, shape cutting, drilling, etc,.

Mechanical Properties of of Titanium Plate (Min.)

Titanium sheet and titanium plate offer a combination of high strength, light weight, formability and corrosion resistance which have made it a most common used high temprature titanium plate and sheet for shipbuilding, aerospace industry, power plants, desalination, metal fabricating industries.

Due to customization, please contact us for satisfying your individualized requirement!


Why Choose Titanium Plate As the Cladding Layer Material?

A notable feature of titanium is its strong corrosion resistance. This is due to its particularly high affinity for oxygen and the ability to form a dense oxide film on its surface, which protects titanium from media corrosion. Titanium metal can form a passivating oxide film on the surface in most aqueous solutions. Therefore, titanium has good stability in acidic, alkaline, neutral salt water solutions and oxidizing media. It has better corrosion resistance than existing stainless steel and other commonly used non-ferrous metals, and can even rival platinum. Therefore, titanium is widely used in various chemical reaction vessels, heat exchanger materials and anti-corrosion fields. However, the disadvantage is that the cost is high, especially when used as structural components. Titanium steel composite panels produced by explosive composite methods , which not only has the corrosion resistance of titanium, but also has the strength and plasticity of ordinary steel plates as structural parts. What is particularly important is that the cost has dropped significantly.


Titanium Metal Products Characteristics

Titanum sheet is used in a wide range of applications. It can be found in applications needing the very blending of weight and strength and harsh environment. Titanium plate and sheet characteristics can be summed up by:

1. Ti sheets have an excellent corrosion resistance & excellent elongation capabilities;
2. Ti sheets have a low density and light weight;
3. Ti sheets and plates have high strength;
4. Titanium has high / low temperature resistance and excellent for use in extreme conditions;
5.  Titanium is non-mangnetic, non-toxic;
6. Titanium is recyclable, environmentally friendly.
