AMST B265 Titanium Alloy Sheet Heat Exchanger Grade 2 Ti 6al 4v Gr5
| Place of Origin | CHINA |
|---|---|
| Brand Name | CSTY |
| Certification | ISO9001:2015 |
| Model Number | ASTM B265 |
| Minimum Order Quantity | 10kgs |
| Price | $35.00 - $125.00/ kg |
| Packaging Details | film and wooden case,carton Packaging can be according to customer requirements. |
| Delivery Time | 15~20 work days |
| Payment Terms | L/C, T/T, Western Union, MoneyGram,Paypal |
| Supply Ability | 5000 Kilogram/Kilograms per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Features | Lightweight, High Strength, Corrosion Resistance, Good Formability | Condition | Anneal,cold Rolled |
|---|---|---|---|
| Processing Service | Bending ,Cutting | Others Name | Titanium Plate,titanium Sheet |
| Grade | GR1, GR2, GR5, GR7, GR9, GR12 | Feature | High Elongation Rate |
| Hardness | Generally In The Range Of 32-38 HRC | Elongation | 24-30% |
| Wall Thickness | 0.3-20mm | Techinique | Cold Rolling Or Hot Rolling |
| Material | Titanium Alloy | Others Mateiral | Titanium |
| Plate Thickness | 1mm To 20mm | With | 300-1000mm |
| Supply Shape | In Coil, In Flat,or Filmed | ||
| Highlight | Gr5 Titanium Alloy Sheet,AMST B265 Titanium Alloy Sheet,Heat Exchanger Titanium Alloy Sheet |
||
Product Description
Introduction
Titanium plates are produced in accordance with both Chinese and American standards.
The national standards include GB/T 3621-2007 and GB/T 13810-2007, while the corresponding American standards are ASTM B265, ASTM F136, ASTM F67, and AMS 4928.
Among them, AMS 4911 Titanium 6Al-4V (Grade 5) is the most widely used titanium alloy, known for its excellent strength-to-weight ratio, corrosion resistance, and high-temperature performance.
Specification
| Product Name | Titanium Plate / Sheet / Coil |
|---|---|
| Standard | AMS 4911 (Ti-6Al-4V) |
| Available Forms | Coil, Sheet, Plate |
| Purity | Ti-6Al-4V (90% Ti, 6% Al, 4% V) |
| Density | 4.43 g/cm³ |
| Melting Point | 1660 °C |
Available Sizes
-
Titanium Coil: thickness 0.12"–0.125"
-
Titanium Sheet: thickness 0.12"–0.125"
-
Titanium Plate: thickness 0.125"–4.0"
-
Common Sheet/Plate Sizes:
-
0.032" × 36" × 96"
-
0.040" × 36" × 96"
-
0.063" × 36" × 96"
-
0.071" × 36" × 96"
-
0.080" × 36" × 96"
-
0.090" × 36" × 96"
-
Mechanical Properties
| Property | Requirement |
|---|---|
| Tensile Strength | ≥ 900 MPa |
| Yield Strength (0.2% offset) | ≥ 825 MPa |
| Elongation (A50mm) | ≥ 10% |
| Hardness | ≤ 36 HRC |
Chemical Composition
| Element | Min (%) | Max (%) |
|---|---|---|
| Aluminium (Al) | 5.50 | 6.75 |
| Vanadium (V) | 3.50 | 4.50 |
| Iron (Fe) | — | 0.30 |
| Oxygen (O) | — | 0.20 |
| Carbon (C) | — | 0.08 |
| Nitrogen (N) | — | 0.05 (500 ppm) |
| Hydrogen (H) | — | 0.015 (150 ppm) |
| Yttrium (Y) | — | 0.005 (50 ppm) |
| Other Elements, each | — | 0.10 |
| Other Elements, total | — | 0.40 |
| Titanium (Ti) | Remainder |
Applications
-
Aerospace Industry
Used in aircraft engine components, airframe structures, and decorative panels.
Titanium’s light density, high strength, and oxidation resistance greatly improve performance and extend service life. -
Medical and Healthcare
Titanium plates’ excellent biocompatibility makes it ideal for medical implants, such as artificial joints, dental implants, and bone fixation devices. -
Marine Engineering
Due to its strong corrosion resistance in seawater, titanium plate is used in offshore oil extraction equipment, underwater pipelines, and ship components. -
Automotive Industry
Titanium plates are used in high-end automotive components such as engine covers and exhaust systems.
Their lightweight improves fuel efficiency and vehicle safety performance.
