Product Description



Technical Characteristics of Titanium Elbows

规格明细 Detailed specification
 Name specification Material  Standard Size range Remark
Elbow 45°,R=1.5D TA1,TA2,TA9,
TA10,GR1,GR7,
GR12,GR16,
N5,N6,N7,UNS N02201,
UNS N02200,Monel 400,
Inconel 625,Hc276,Zr702,Zr705
GB/T27684
GB/T12459
ASME B16.9
ASME B16.11

 Ф18~Ф114.3(1/2” ~4”),the thickness from2mm to 9mm.

Ф133~中1524(5" ~60")3mm~30mm.
Welded Ф133~Ф1524(5”~60”),the thickness from3mm to 30mm.


Non standard products
can be produced according
to customer's requirements
or drawing



90°,R=1.5D
90°,R=1.0D
90°,R=3D
180°,R=1.5D
180°,R=1.0D

 Technical Characteristics of Titanium Elbows



Titanium elbows, formed from high-purity Ti/Ti-alloys (e.g., Gr2/Gr5) via precision cold-forming/hot-push processes, serve as critical flow-direction components in piping systems. Key advantages include:
1. Superior Media Compatibility: Withstands extreme corrosives (boiling HCl, seawater, chlorides), offering 10x+ lifespan vs stainless steel
2. Fluid Dynamics Optimization: Mirror-polished interior (Ra≤0.8μm) reduces turbulence, boosting flow efficiency by 15%+
3. Topological Flexibility: Supports 30°-180° custom angles for complex layouts
4. Lightweight Integration: 60% density of steel, drastically cuts structural loads
ASME B16.9 30/45/60/90/180 Degree GR2 Elbows For Industrial Project 0
Critical Applications:
- Subsea oil/gas: Resists H₂S corrosion at 3000m depth
- Nuclear plants: Low thermal neutron absorption ensures radiation safety
- Pharma GMP pipelines: Zero metallic ion contamination
- Aerospace fuel systems: Stable performance from -196°C to 550°C

Requires specialized processes like laser-tracked straightening to control springback. Despite higher cost, remains irreplaceable for high-purity/ultra-corrosive media transfer.
