Titanium Fasteners Gr1 Gr2 Gr5 Bolts And Nuts Screws For Industrial
| Place of Origin | CHINA |
|---|---|
| Brand Name | CSTY |
| Certification | GB/T19001-2016/ISO9001:2015 |
| Model Number | DIN ISO |
| Minimum Order Quantity | 100pcs |
| Price | $0.20 - $4.20/ Piece |
| Packaging Details | wooden case,carton Packaging can be according to customer requirements. |
| Delivery Time | 15~20 work days |
| Payment Terms | L/C, T/T, Western Union, MoneyGram,Paypal |
| Supply Ability | 1000 pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Length | 3-1000mm | Application | Aerospace, Automotive, Marine, Chemical, Medical, Sports Equipment |
|---|---|---|---|
| Equipment | CNC Machining Centres | Durability | High |
| Versatility | Suitable For Various Applications | Easy To Install | Easy To Install And Remove |
| Origin | Baoji, Shaanxi, China | Drive Type | Phillips, Slotted, Torx, Hex, Square |
| Technique | CNC Machining | Packing | Wooden Box Or Carton Box |
| Technical | Forge,welding | Type | Precision Nonstandard Parts(OEM Service) |
| Tensile Strength | Up To 950 MPa | Processing | CNC |
| Weight | Lightweight | ||
| Highlight | Gr2 Titanium Fasteners,Industrial Titanium Fasteners,Gr5 Titanium Fasteners |
||
Product Description
Description
The Titanium Gr2 Bolt DIN912 is a high-performance fastener made from commercially pure titanium or titanium alloy. Known for its lightweight, high strength, and excellent corrosion resistance, this bolt type is ideal for demanding applications in aerospace, medical, and automotive industries.
Compared with traditional steel fasteners, titanium bolts provide a superior strength-to-weight ratio and outstanding durability, making them suitable for environments requiring high performance and long service life.
Specifications
| Item | Details |
|---|---|
| Product Name | Titanium Gr2 Bolt DIN912 / Hex Socket Head Titanium Bolt |
| Grade | Gr2, Gr5 |
| Size | M1.6 – M30 |
| Pitch | 1.0 / 1.25 mm |
| Color | Titanium natural, green, blue, gold, black, purple |
| Surface Finish | Polished, Pickling, Anodized |
| Head Style | Hex Socket Head |
| Standard | DIN912 |
| Material | Commercially Pure Titanium (Gr2) or Titanium Alloy (Gr5) |
Chemical Composition & Physical Properties
Physical Properties
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
|---|---|---|---|
| Gr1 | 240 | 170 | 24 |
| Gr2 | 345 | 275 | 20 |
| Gr4 | 550 | 483 | 15 |
| Gr5 | 895 | 828 | 10 |
| Gr7 | 400 | 275 | 18 |
| Gr9 | 620 | 483 | 15 |
| Gr12 | 483 | 348 | 18 |
| Gr23 | 793 | 759 | 10 |
Chemical Composition
| Grade | Fe (%) | O (%) | N (%) | C (%) | H (%) | Pd (%) | Al (%) | V (%) | Ni (%) | Mo (%) | Ti |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Gr1 | 0.20 | 0.18 | 0.03 | 0.08 | 0.015 | — | — | — | — | — | Balance |
| Gr2 | 0.30 | 0.25 | 0.03 | 0.08 | 0.015 | — | — | — | — | — | Balance |
| Gr4 | 0.50 | 0.40 | 0.05 | 0.08 | 0.015 | — | — | — | — | — | Balance |
| Gr5 | 0.40 | 0.20 | 0.05 | 0.08 | 0.015 | — | 5.5–6.7 | 3.5–4.5 | — | — | Balance |
| Gr7 | 0.30 | 0.25 | 0.03 | 0.08 | 0.015 | 0.12–0.25 | — | — | — | — | Balance |
| Gr9 | 0.25 | 0.15 | 0.03 | 0.08 | 0.015 | — | 2.5–3.5 | 2.0–3.0 | — | — | Balance |
| Gr12 | 0.30 | 0.25 | 0.03 | 0.08 | 0.015 | — | 0.6–0.9 | 0.2–0.4 | — | — | Balance |
| Gr23 | 0.25 | 0.03 | 0.03 | 0.08 | 0.0125 | — | 5.5–6.5 | 3.5–4.5 | — | — | Balance |
Applications
Titanium bolts and screws are used across numerous industries due to their unique combination of strength, low weight, and corrosion resistance.
1. Aerospace Industry
Titanium bolts are extensively used in aircraft and spacecraft components such as fuselages, engines, fuel tanks, and structural assemblies. Their low density, high tensile strength, and resistance to extreme environments make them ideal for flight applications.
2. Biomedical Field
Titanium’s excellent biocompatibility allows these fasteners to be used in orthopaedic, dental, and cardiovascular implants. Titanium does not cause allergic reactions or toxicity, making it a preferred material for medical devices and prosthetics.
3. Marine Engineering
In marine and offshore environments, titanium bolts withstand corrosive saltwater and high-pressure conditions. They are ideal for ships, offshore platforms, and underwater equipment requiring long-term reliability.
4. Automotive Industry
Titanium fasteners reduce vehicle weight while maintaining strength, contributing to energy savings, emission reduction, and performance optimisation. They are commonly used in engines, suspensions, and performance vehicle assemblies.
5. Other Applications
Titanium bolts are also used in:
Chemical equipment (reactors, heat exchangers)
Energy systems (power station condensers)
Food processing machinery
Sports equipment (bicycles, golf clubs)
Precision instruments and luxury goods
Advantages
Lightweight yet high-strength
Excellent corrosion and heat resistance
Non-magnetic and non-toxic
Long service life
Beautiful anodised finish options
Suitable for high-precision, high-demand industries
