OD108mm Gr7 Titanium Alloy Pipe Round And Seamless Tubing For Geothermal Plant
| Place of Origin | Shaanxi, China |
|---|---|
| Brand Name | Changsheng |
| Certification | ISO9001：2015 |
| Model Number | Gr7 Titanium Alloy Pipe Seamless Tubing |
| Minimum Order Quantity | 50kg |
| Price | USD 190.0/KG - USD 210.0/KG |
| Packaging Details | Soft film wrapped inside, export standard crate outside. |
| Delivery Time | 3-5 work days |
| Payment Terms | L/C, T/T |
| Supply Ability | 30 Tons per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Grade 7 Ti-0.15Pd Alloy (UNS R52400) | Diameter | OD108mm |
|---|---|---|---|
| Wall Thickness | 3mm | Surface | Acid Washing Surface |
| Shape | Round Titanium Tubing | Production Standard | ASTM B338, ASTM B337, ASTM B861 |
| Application | Chemical, Vessel Fabrication, Plating And Anodizing | Advantage | Strong Crevice Corrosion Resistance |
| Tube Origin | Baoji City, China | Supply Company | Baoji City Changsheng Titanium Co,. |
| Highlight | OD108mm Titanium Alloy Pipe,Round Seamless Titanium Alloy Pipe,Gr7 Titanium Alloy Pipe |
||
Product Description
OD108mm Gr7 Titanium Alloy Pipe Round And Seamless Tubing For Geothermal Plant
Gr7 titanium alloy pipe, round and seamless tubing, we now have dia108mm Gr7 titanium tubes in stock, with high quality and competitive price, meet the short time deadline. Grade 7/3.7235 Ti-Pd alloy(UNS R52400) is highly resistant to corrosion in reducing acids and localized attack in hot halide media. Gr7 Titanium pipe are certainly viable candidates for geothermal systerm components when common stainless steels have previously failed or are anticipated to exhibit marginal performance. Titanium seamless tubing grade 7 become preferred materials in geothermal systems because hot, oxidizing-chloride conditions are known to cause severe localized attack of stainless steel and nickel-base alloys.
Gr7 Titanium Alloy Pipe Stock Size
Grade: Titanium alloy, Grade 7(Ti-Pd)/3.7235, UNS R52400
Standard: ASTM B338 ASTM B337 ASTM B861
Outside Diameter: 108mm
Wall thickness: 3mm
Tube Surface: pickling surface
Price: competitive price
Lead time: 3 days
Grade 7(Ti-Pd)/3.7235, UNS R52400 Chemical Composition (wt)%
| Element | Impurity ≤ | |||||||
| Ti | Pd | Fe | C | N | H | O | Other Elements | |
| Single | Total | |||||||
| Balance | 0.12 - 0.25 | 0.25 | 0.10 | 0.03 | 0.015 | 0.20 | 0.10 | 0.40 |
Titanium Tubes Mechanical Properties
|
ASTM Grade
|
Alloy composition | Tensile strength | Yield strength | Elongation % | ||
| ksi | Mpa | ksi | Mpa | |||
|
GR1
|
Unallyed Ti(Pure)35A-CP1 | 35 | 240 | 25 | 170 | 24 |
| GR2 | Unallyed Ti(Pure)50A-CP2 | 50 | 345 | 40 | 275 | 20 |
| GR5 | Ti 6Al 4V | 130 | 895 | 120 | 828 | 10E |
| GR7 | Ti-Pd | 50 | 345 | 40 | 275 | 20 |
| GR9 | Ti 3AI 2.5V | 90 | 620 | 70 | 483 | 15F |
General Introduction of Gr7 Titanium Alloy Metal Material
Ti-0.2Pd (Grade 7) Titanium alloy with addition of small quantities of precious metals palladium and pure industrial titanium The palladium of the alloy improves not only the corrosion resistance in reducing medium, but also its corrosion resistance in oxidizing medium. In high temperature and high concentration of various chloride media, Ti-0.2Pd alloy has the strongest anti-crevice corrosion resistance. Ti-0.2Pd has various properties similar to industrial pure titanium, so the alloy is widely used in chemical industry, especially petrochemical industry.
Gr7 Titanium Tube Industrial Applications
Oil and Gas Industry
Power Plant Industry
Marine Industry
Marine Industry
Seawater desalination industry
Chemical and petrochemical industry
Pulp and paper industry
Chemical and petrochemical industry
Pulp and paper industry
Plating and anodizing industry
Medical industry
Nuclear industry
Medical industry
Nuclear industry
Tags: Gr7 titanium pipes, Titanium Alloy Pipes, Grade 7 Titanium Geothermal Brine Well Tubular
