ASTM B338 Fabricated Welded Titanium Seamless Pipe Tube Chemical
| Place of Origin | China |
|---|---|
| Brand Name | Changsheng |
| Certification | ISO 9001;2015 |
| Model Number | ASTM B338 |
| Minimum Order Quantity | 10kg |
| Price | $15.00 - $30.00/ kg |
| Packaging Details | Stardard export package |
| Delivery Time | 15~20 work days |
| Payment Terms | L/C, T/T, Western Union, MoneyGram,paypal |
| Supply Ability | 2000kgs/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Certifications | ISO 9001:2015 | Finish | Polished |
|---|---|---|---|
| Tubes Supply State | Annealed | Specifications | Custom Size |
| Condition | M | Application Fields | Aerospace, Medical, Marine |
| Oem | Yes | Seam Type | Seamless |
| Shape | Tubing | Tube Origin | Baoji City, China |
| Flexibility | High | Tubes Type | Seamless Tubes, Welded Tubes |
| Keywords | Titanium Tubular Targets | Standard | ASTM B338 |
| Inventory | Large Stock, Ready To Go | ||
| Highlight | ASTM B338 Seamless Titanium Pipe Tube,Fabricated Seamless Titanium Pipe Tube,Welded Seamless Titanium Pipe Tube |
||
Product Description
Advantages
High resistance to corrosion
Non-magnetic properties
Low density and high strength
Excellent heat transfer capability
High melting point
Superior tensile strength
Specifications
Seamless Titanium Tube / Pipe
Grade: Gr1, Gr2, Gr7, Gr9, Gr11, Gr12, Gr16, etc.
Outer Diameter: 3–110 mm
Wall Thickness: 0.1–5.5 mm
Length: ≤19,000 mm
Welded Titanium Tube / Pipe
Grade: Gr1, Gr2, Gr7, Gr9, Gr11, Gr12, Gr16, etc.
Outer Diameter: 10–1,000 mm
Wall Thickness: 0.5–5.5 mm
Length: ≤19,000 mm
Standards
ASTM B338 / ASME SB338
ASTM B337 / ASME SB337
ASTM B861 / ASME SB861
ASTM B862 / ASME SB862
AMS 4911, AMS 4928
Material Grades
Gr1, Gr2, Gr5, Gr7, Gr9, Gr11, Gr12, etc.
Surface Treatment
Pickled, polished, or bright finish
Features
-
Low density with high strength
-
Excellent corrosion resistance
-
Good resistance to heat effects
-
Outstanding cryogenic performance
-
Non-magnetic and non-toxic
-
Excellent thermal conductivity
-
Low modulus of elasticity
Applications
Titanium has proven to be an indispensable material across numerous industries due to its unique combination of strength, corrosion resistance, and light weight. It is widely used in:
Aerospace and aviation – for airframes, engines, and structural tubing
Chemical processing – for reactors, heat exchangers, and piping systems
Power generation – particularly in surface condensers and seawater cooling systems
Oil and gas – for offshore and subsea equipment
Marine industry – due to its resistance to seawater corrosion
Medical field – for surgical instruments and implants
Titanium tubes can be easily fabricated, welded, and formed for various industrial uses.
There are currently 38 titanium grades approved under ASME B338 and ASTM B338, including Grades 1, 2, 3, 7, 9, 11, 12, 16, 17, 26 (TiRU-26TM), and 27 (TiRU-27TM).
Among these, Grade 2 titanium is the most commonly used, especially for power plant surface condensers.
Typical titanium alloys used for tubing include Ti-3Al-2.5V and Ti-6Al-4V.
