Sputtering Target Chromium Cr 100x40mm Hot Isostatic Pressing
| Place of Origin | China |
|---|---|
| Brand Name | CSTI |
| Certification | ISO9001:2015 |
| Model Number | 20221110 |
| Minimum Order Quantity | 1piece |
| Price | $55.00 - $150/pc |
| Packaging Details | Vacuum sealed package inside; export wooden case or carton outside |
| Delivery Time | 7~20 work days |
| Payment Terms | T/T, L/C |
| Supply Ability | 10000 Piece/Pieces per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Chromium/Cr | Purity | 99.5%~99.95% |
|---|---|---|---|
| Size | φ100*40mm, φ150*30mm, φ155*30, φ80*40mm Etc | Forming Process | Hot Isostatic Pressing(HIP) |
| Shape | Rectangular Target, Arc Target, Ring Target And Large Aspect Ratio Integrally Formed Tube Target Etc | Application | Decorative Coating, Tool Coating, Flat Display Coating, Thin Film Solar Industry, Flat Panel Display Industry, Energy-saving Glass Industry, Optical Coating Industry (such As Automobile Rearview Mirror Coating) |
| High Light | Metal Sputtering Chromium Target,Hot Isostatic Pressing Chromium Target,Rectangular Cr Planar Target |
||
Product Description
Chromium sputtering target
The chromium sputtering target material is produced by the advanced hot isostatic pressing (HIP) process. sputtering target include rectangular target, arc target, ring target and large aspect ratio integrally formed tube target, etc., with controllable purity and density, and fine and uniform grains , Long service life and other advantages.
Purity: 99.5%~99.95%;
Forming process: hot isostatic pressing(HIP);
Conventional size: ID55*OD70*L, ID125*OD153*L, φ100*40mm, φ150*30mm, φ155*30, φ80*40mm, etc.;
Application: decorative coating, tool coating, flat display coating, thin film solar industry, flat panel display industry, energy-saving glass industry, optical coating industry (such as automobile rearview mirror coating), etc.
| Chromium sputtering target | Product performance | ||
| Purity | 99.5 | 99.95 | |
| Density g/cm3 | ≥7.12 | ≥7.12 | |
| Grain size/μm | ≤100 | ≤100 | |
| Total content of metallic impurities/ppm | ≤5000 | ≤500 | |
| Thermal conductivity/W/m.K | 60 | 100 | |
| Coefficient of thermal expansion/1/K | 8×10-6 | 8×10-6 | |
| Size/mm | Planar target | ≤1600×500 | ≤1600×500 |
| Rotating target | Integral formingby HIP Length≤4000 Thickness≤15 |
Integral formingby HIP Length≤4000 Thickness≤15 |
|
Chromium sputtering target 2N5 (Trace elements)PPM ≥7.12g/cm3
| Composition | Fe | Al | Si | C | S | O | N |
| Standard | ≤1500 | ≤1200 | ≤1500 | ≤200 | ≤50 | ≤1400 | ≤300 |
| Test values | 980 | 300 | 600 | 62 | 50 | 1200 | 200 |
Chromium sputtering target 2N8 (Trace elements)PPM ≥7.12g/cm3
| Composition | Fe | Al | Si | C | S | O | N |
| Standard | ≤800 | ≤300 | ≤400 | ≤200 | ≤50 | ≤1000 | ≤100 |
| Test values | 740 | 78 | 92 | 84 | 50 | 340 | 30 |
Chromium sputtering target 3N (Trace elements)PPM ≥7.12g/cm3
| Composition | Fe | Al | Si | C | S | O | N |
| Standard | ≤500 | ≤100 | ≤150 | ≤150 | ≤30 | ≤500 | ≤100 |
| Test values | 290 | 47 | 80 | 90 | 28 | 450 | 50 |
Chromium sputtering target 3N5 (Trace elements)PPM ≥7.12g/cm3
| Composition | Fe | Al | Si | Cu | Ｎi | C | S | O | N |
| Standard | ≤100 | ≤50 | ≤50 | ≤10 | ≤50 | ≤50 | ≤30 | ≤150 | ≤80 |
| Test values | 50 | 45 | 40 | 7 | 10 | 24 | 27 | 137 | 30 |
Other targets can also be supplied
| Item | Purity | Density | Coating color | Shape | Standard size | |
| Titanium Aluminum(TiAl) Alloy target | 2N8-4N | 3.6-4.2 | Rose gold/coffee/champagne gold | cylinder/planar | (D)70/100*(H)100-2000mm |
solar photovoltaic industry, decorative coatings industry, flat |
| Pure chrome (Cr)target | 2N7-4N | 7.19 | gun grey/black | cylinder/planar | (D)70/100*(H)100-2000mm | |
| Pure Titanium(Ti) target | 2N8-4N | 4.51 | gold/rose gold/blue/rainbow/light black/gun grey | cylinder/planar | (D)70/100*(H)100-2000mm | |
| Pure Zirconium(Zr) target | 2N5-4N | 6.5 | light gold | cylinder/planar | (D)70/100*(H)100-2000mm | |
| Pure Aluminium(Al) target | 4N-5N | 2.7 | silver | cylinder/planar | (D)70/100*(H)100-2000mm | |
| Pure Nickel (Ni) target | 3N-4N | 8.9 | nickel | cylinder/planar | (D)70/100*(H)100-2000mm | |
| Pure Niobium (Nb) target | 3N | 8.57 | white | cylinder/planar | (D)70/100*(H)100-2000mm | |
| Pure Tantalum(Ta) target | 3N5 | 16.4 | black/pure | cylinder/planar | (D)70/100*(H)100-2000mm | |
| Pure Molybdenum (Mo) target | 3N5 | 10.2 | black | cylinder/planar | (D)70/100*(H)100-2000mm | |
| Remarks: Size can be customizaed according to specical requirements | ||||||
Product Advantage
01 High chemical purity
02 Low gas content
03 Close to 100% density
04 Uniform grains
05 Dense and homogeneous inner structure
Application Field of sputtering target
solar photovoltaic industry
decorative coatings industry
flat panel display industry
architectural glass/automotive glass industry
flexible winding coating industry
optical data storage industry
optical communication/optical industry
magnetic data storage as well as semiconductor industry
Tag: Chromium sputtering target,Cr target,Cr planar target,decorative coating, tool coating, flat display coating, thin film solar industry, flat panel display industry, energy-saving glass industry, optical coating industry
