GR5 Titanium Wire ASTM B863 size 0.1 to 8mm for Manufacture Ship Parts

Place of Origin CHINA
Certification ISO9000:2015
Model Number GR5
Minimum Order Quantity 10KG
Price According to quantity
Packaging Details Clients’ requirement
Delivery Time 10 working days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 300 tons per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Material Grade Grade5 Technical Forged,welding
Surface Polished Key Words Titanium Welding Wire
Category Shape Memory Surface Color Polished/black/blue/yellow/purple
Materials Titanium Wire Diameter 0.1mm To 8.0mm
High Light

Manufacture Ship Parts Titanium Wire


ASTM B863 Titanium Wire


GR5 Titanium Wire

Leave a Message
Product Description

GR5 Titanium Wire ASTM B863 size 0.1 to 8mm for Manufacture Ship Parts


ASTM B863 for industrial us

ASTM F136 for medical use

AMS 4928 for military use




GR5 titanium wire is a type of titanium alloy wire material, composed of elements such as titanium, aluminum and vanadium. It has the characteristics of high strength, low density, good corrosion resistance and high temperature stability, so it is widely used in aerospace, shipbuilding, medical equipment, chemical equipment manufacturing.


1. It is used to manufacture aircraft parts, such as screws, bolts, fasteners, etc. Titanium alloy has high strength and rigidity while being light in weight, so it can reduce the weight of the aircraft and improve the flight performance.


2. It is used to manufacture ship parts, such as hull structure, fittings on deck, etc, due to titanium has high corrosion resistance and high temperature stability, and can be used in harsh environments such as seawater.


3. It is used to manufacture medical devices, such as implants, artificial joints, etc, because it has good biocompatibility and can reduce the rejection of implants.


4. It is used to manufacture chemical equipment, such as reactors, heaters, heat exchangers, etc. Titanium alloy has excellent corrosion resistance and high-temperature stability, and can withstand the erosion of corrosive media such as strong acid and strong alkali.


Manufacturing Standard: ASTM B863 for industrial use, ASTM F136 for medical use, the AMS 4928 for military use


Size: 0.1~8mm


Surface: polished or pickling treatment


Type: straight or in coil


Minimum Order Quantity (MOQ): 10KG


Gr5 Chemical Properties

Chemical composition
Grade N C H Fe O Al V Ti Other, max
5 0.05 0.08 0.015 0.40 0.20 5.5-6.75 3.5-4.5 Bal 0.4

Gr5 Mechanical Details

Mechanical Properties(>%)
Grade Tensile Strength(min) Yeild Strength(0.2% offset)) Elongation(%)
ksi MPa Min
      Ksi Mpa
5 130 895 120 828 10


Advantages Compared With Aluminum Alloy.


1. GR5 titanium wire possesses higher thermal strength, allowing it to be used at service temperatures several hundred degrees higher than those for aluminum alloys. Grade 5 titanium wire can maintain the required strength at medium temperatures and is capable of operating for extended periods at temperatures ranging from 450 to 500°C. When considering specific strength, while aluminum alloys significantly decrease in strength at 150°C, GR5 titanium wire can withstand temperatures up to 500°C, whereas aluminum alloys typically cannot exceed 200°C.


2. The GR5 titanium wire offers superior corrosion resistance, performing excellently in moist atmospheres and seawater environments. Its resistance to corrosion far surpasses that of stainless steel; it is particularly impervious to pitting corrosion, acid corrosion, and stress corrosion cracking. It also exhibits outstanding resistance to alkalis, chlorides, chlorine-containing organic substances, nitric acid, and sulfuric acid. However, the corrosion resistance of GR5 titanium wire is poor against media containing reducing oxygen and chromium salts.
